Engineered to deliver defect-free welds and optimal arc stability, TIG Welding Machines manufactured by Canary Electricals Pvt. Ltd. represent the gold standard in modern metal fabrication. Developed under our registered Vulcan brand, these machines integrate cutting-edge inverter technology with high-frequency arc initiation, catering specifically to global procurement demands in heavy industries, pressure vessel manufacturing, aerospace components, and pipe fabrication.
Each DC TIG Welder unit undergoes comprehensive multi-stage testing in our ISO 9001:2015 certified manufacturing plant in Morbi, Gujarat, India. Built to endure harsh tropical temperatures, voltage fluctuations, and continuous industrial operations, our TIG welding solutions guarantee consistent penetration, minimal spatter, and superior aesthetic bead quality on stainless steel, mild steel, copper, and titanium alloys.
Explore our flagship DC TIG and Inverter TIG Welding Equipment engineered for global export markets.
Compact, heavy-duty DC TIG welding unit featuring advanced energy-saving control and high thermal resistance for precision metal arc welding.
| Output Current: | 10 – 200 A |
| Dimension (L*W*H): | 480 x 180 x 315 mm |
| Efficiency: | 85% Energy Efficient |
| Weight / Insulation: | 21 kg | Grade H |
| Supply Ability: | 20 Units / Day |
Versatile manual and automatic dual-mode TIG welder designed for industrial repair shops, structural steel fabrication, and pipe welding.
| Arc Current: | 200 Ampere |
| Cooling Method: | Forced Air Cooled |
| Input Voltage: | 220V ± 10% / 50-60Hz |
| Input Current: | 22 A |
| Delivery Time: | 1 Week (Worldwide Shipping) |
Standard engineering parameters for Vulcan Series TIG Welding Equipment.
| Technical Parameter | DC TIG 200A Series | DC TIG 300A Heavy Series | Industrial 400A TIG System |
|---|---|---|---|
| Rated Input Voltage (V) | 1-Phase AC 220V ± 15% | 3-Phase AC 415V ± 10% | 3-Phase AC 415V ± 10% |
| Output Current Range (A) | 10 – 200 A | 15 – 300 A | 20 – 400 A |
| Duty Cycle @ 40°C | 60% @ 200A | 60% @ 300A | 100% @ 310A / 60% @ 400A |
| Arc Start Mechanism | HF Arc Ignition / Lift Arc | HF Arc Ignition | HF Arc Ignition |
| Insulation Class | Class H | Class H | Class H |
| Protective Grade | IP21S / IP23 | IP21S / IP23 | IP23S Industrial |
| Gas Pre/Post Flow Time | 0.5 - 15 Seconds (Adjustable) | 0.5 - 15 Seconds (Adjustable) | 0.5 - 20 Seconds (Adjustable) |
Our TIG machines are deployed in high-spec engineering sectors globally.
Ideal for food processing equipment, dairy tanks, and architectural stainless steel work requiring mirror-finish welds.
Meets x-ray quality weld seam inspection requirements for high-pressure boilers, heat exchangers, and chemical containers.
Precision root pass and thin-gauge sheet welding for exhaust systems, alloy frames, and precision brackets.
We offer customized transformer and inverter windings compatible with global voltage standards including 110V, 220V, 380V, 415V, and 440V at both 50Hz and 60Hz frequency ratings.
Yes, Canary Electricals provides OEM manufacturing services for qualified B2B importers, distributors, and machinery brands, offering custom paint colors, badging, and instruction manuals.
All machines are sealed inside moisture-proof poly-wrap, cushioned with heavy-duty foam corner guards, and enclosed in ISPM-15 compliant export wooden crates or corrugated cartons.
We back our Vulcan TIG welding machines with a standard 12-month manufacturer warranty alongside ready availability of replacement circuit boards, high-frequency units, and torches.
